PS1800 vertical glass sandblasting machine
1. Unit Price: FOB China main port USD8,990.00
2. Payment term: 30% of total value as down payment, the balance paid before shipment.
3. Delivery: 30 days after received the down payment.
4. Installation: The seller is responsible for the machine installation as buyer requires, and the buyer is responsible for round-trip air tickets, local transportation, lodging and meals for the engineer. The installation charge is USD150 per person per working day. The installation period should not exceed 10 days.
0102
Description
Glass Automatic Sandblasting Machine, touch screen PLC control, either manual or automatic operate function, with 3 automatic blasting guns and 1 manual operation gun, suitable for processing flat glass thickness 5-50mm for steric pattern, timing belts glass transmission, when glass arrive the position for sandblasting, the 3 blasting guns driven move up-and-down to spurt out sand. The height and the width of sandblasting can be adjusted according to the requirement. The advantages of the belts are stable on transmission, high efficiency and easy maintenance. The drive structure of the blasting gun is outside the machine which is good for a long period of working and daily maintenance.
Specification
| Model |
PS-1800 |
| Max. Size |
1800mm |
| Min. Size |
350*350mm |
| Thickness of Glass |
5-50mm |
| Sandblasting Speed |
15-20m²/h |
| Total Power |
3.5kW |
| Overall size |
5500x1500x2600mm |
| Weight |
1400kg |
| Voltage |
customized |
1）Nozzle inner diameter: 8mm
2）Nozzle up/down speed: 8m/min
3）Glass conveyor speed: 5m/min
4）Production capability: 20m²/h
5）Conveyor belt width: 60mm
6）Rising belt width: 32mm
7）Min glass size: 350
8）Rising motor power: 0.37kw
9）Conveyor motor power: 0.75kw
10）Rust blower power: 2.3kw
11）Rust extrusion : cloth bag dust
12）Filter dust method: electricity
13）Working air consumtion: > 3 m²/min
14）Air pressure: 0.6-0.8Mpa
15）Total power: 3.5 kw
Component list
PLC : Mitsubishi,Japan
Touch screen: Xiankong,Shenzhen
Electricity part: CHNT,Zhejiang
Code editor: Rongde,Jilin
Belt: Foshan,China
Nozzle : China
Turbine case : Mingyiyang,Guangdong
Turbine case motor: China
Dust motor: xietong motor,Guangdong
Blower motor: China
Working air source requirement:
Air compressor : total power: 22KW,air comsuption: at least 3 cbm.min
Air storage tank: at least 1 cbm
Filter: it must match the air compressor ,it just filter the moisture ,no need to dry
Glass sample as follows
Machine parts
